Managing CI/CD pipelines with Arm compute resource classes

Developer Advocate, CircleCI

Arm processors and architectures are becoming widely available as development teams adopt them as compute nodes in many application infrastructures. Organizations that need to run microservices, application servers, databases, and other workloads in a cost-effective way will continue to turn to the Arm architecture.

CircleCI customers who need Arm-based compute have several options. They can take advantage of the speed, flexibility, and convenience of CircleCI’s hosted execution environments by accessing our Arm-enabled Docker or machine executors. Teams that want additional control over their infrastructure can also use self-hosted runners on their own Arm compute resources. In this tutorial, I will demonstrate how to use cloud-based resources in your pipelines to build, test, and deploy applications for Arm.

Arm support on the Docker executor
available now

Learn More

Prerequisites

Before you can get started with this tutorial, you need to complete a number of tasks:

Git clone this arm-executors-project example repo GitHub
Sign-up for a CircleCI account
- Set up arm-executors-project in CircleCI
Create an Amazon Web Services (AWS) Account
- Create an AWS IAMS user with programmatic access
  - Assign this user AWS ECS permissions
  - Generate AWS Access keys and secrets and save the AWS_ACCESS_KEY_ID and AWS_SECRET_ACCESS_KEY for later use
Create a Docker Hub account
- Create a Docker Hub Access Token
Install Terraform CLI locally
- Create a Terraform Cloud Account
- Create a new Terraform Cloud organization
- Create a new Terraform Cloud workspace named arm-aws-ecs and choose the "No VCS connection" option
- Enable local execution mode in the arm-aws-ecs workspace
- Create a new Terraform API token
Create these following project environment variables in CircleCI
- AWS_ACCESS_KEY_ID: enter the value of the AWS Access Key ID
- AWS_SECRET_ACCESS_KEY: enter the value of the AWS Secret Access Key
- DOCKER_LOGIN: enter the value of your Docker username
- DOCKER_PWD: enter the value of Docker Hub Access token
- TERRAFORM_TOKEN: enter the value of Terraform API Token

Arm compute resource classes

The following sections of this tutorial will demonstrate configuring and executing CI/CD pipelines on Arm-based executors along with demonstrating how to create, deploy, and destroy AWS ECS clusters based on AWS Graviton2 compute nodes using Terraform for infrastructure as code.

Implement Arm compute within the config.yml

The pipeline config example below shows how to define Arm resource classes.

version: 2.1
orbs:
  node: circleci/node@7.1.0
jobs:
  run-tests:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - node/install-packages:
          override-ci-command: npm install
          cache-path: ~/project/node_modules
      - run:
          name: Run Unit Tests
          command: |
            ./node_modules/mocha/bin/mocha test/ --reporter mochawesome --reporter-options reportDir=test-results,reportFilename=test-results
      - store_test_results:
          path: test-results
      - store_artifacts:
          path: test-results
  build_docker_image:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - run:
          name: "Build Docker Image ARM V8"
          command: |
            export TAG='0.1.<< pipeline.number >>'
            export IMAGE_NAME=$CIRCLE_PROJECT_REPONAME
            docker build -t $DOCKER_LOGIN/$IMAGE_NAME -t $DOCKER_LOGIN/$IMAGE_NAME:$TAG .
            echo $DOCKER_PWD | docker login -u $DOCKER_LOGIN --password-stdin
            docker push -a $DOCKER_LOGIN/$IMAGE_NAME
workflows:
  build:
    jobs:
      - run-tests
      - build_docker_image

In this code example, the run-tests: job shows how to specify a machine executor and assign it an Arm compute node resource class. The image: key specifies the operating system assigned to the executor. The resource_class: specifies which CircleCI resource class to utilize. In this case we’re using the arm.medium resource class type, which enables pipelines to execute and build code on and for Arm architectures and resources. The build_docker_image: job is a great way to use the arm.medium resource class to build an Arm64 capable Docker image that can be confidently deployed to Arm compute infrastructures, such as AWS Graviton2.

version: 2.1
orbs:
  node: circleci/node@7.1.0
commands:
  install_terraform:
    description: "specify terraform version & architecture to use [amd64 or arm64]"
    parameters:
      version:
        type: string
        default: "0.13.5"
      arch:
        type: string
        default: "arm64"
    steps:
      - run:
          name: Install Terraform client
          command: |
            cd /tmp
            wget https://releases.hashicorp.com/terraform/<<
              parameters.version >>/terraform_<<
              parameters.version >>_linux_<<
              parameters.arch >>.zip
            unzip terraform_<< parameters.version >>_linux_<<
              parameters.arch >>.zip
            sudo mv terraform /usr/local/bin
jobs:
  run-tests:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - node/install-packages:
          override-ci-command: npm install
          cache-path: ~/project/node_modules
      - run:
          name: Run Unit Tests
          command: |
            ./node_modules/mocha/bin/mocha test/ --reporter mochawesome --reporter-options reportDir=test-results,reportFilename=test-results
      - store_test_results:
          path: test-results
      - store_artifacts:
          path: test-results
  build_docker_image:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - run:
          name: "Build Docker Image ARM V8"
          command: |
            export TAG='0.1.<< pipeline.number >>'
            export IMAGE_NAME=$CIRCLE_PROJECT_REPONAME
            docker build -t $DOCKER_LOGIN/$IMAGE_NAME -t $DOCKER_LOGIN/$IMAGE_NAME:$TAG .
            echo $DOCKER_PWD | docker login -u $DOCKER_LOGIN --password-stdin
            docker push -a $DOCKER_LOGIN/$IMAGE_NAME
  deploy_aws_ecs:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - run:
          name: Create .terraformrc file locally
          command: echo "credentials \"app.terraform.io\" {token = \"$TERRAFORM_TOKEN\"}" > $HOME/.terraformrc
      - install_terraform:
          version: 0.14.2
          arch: arm64
      - run:
          name: Deploy Application to AWS ECS Cluster
          command: |
            export TAG=0.1.<< pipeline.number >>
            export DOCKER_IMAGE_NAME="${DOCKER_LOGIN}/${CIRCLE_PROJECT_REPONAME}"
            cd terraform/aws/ecs
            terraform init
            terraform apply \
              -var docker_img_name=$DOCKER_IMAGE_NAME \
              -var docker_img_tag=$TAG \
              --auto-approve
  destroy_aws_ecs:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - run:
          name: Create .terraformrc file locally
          command: echo "credentials \"app.terraform.io\" {token = \"$TERRAFORM_TOKEN\"}" > $HOME/.terraformrc
      - install_terraform:
          version: 0.14.2
          arch: arm64
      - run:
          name: Destroy the AWS ECS Cluster
          command: |
            cd terraform/aws/ecs
            terraform init
            terraform destroy --auto-approve
workflows:
  build:
    jobs:
      - run-tests
      - build_docker_image
      - deploy_aws_ecs
      - approve_destroy:
          type: approval
          requires:
            - deploy_aws_ecs
      - destroy_aws_ecs:
          requires:
            - approve_destroy

Deploy to AWS ECS

The code example in the previous section shows how to leverage the Arm resource classes and within a pipeline. In this section, I will show you how to extend that code to create AWS resources such as ECS clusters. I will create these resources with underlying AWS Graviton2 EC2 compute nodes using Terraform and infrastructure as code.

version: 2.1
orbs:
  node: circleci/node@7.1.0
commands:
  install_terraform:
    description: "specify terraform version & architecture to use [amd64 or arm64]"
    parameters:
      version:
        type: string
        default: "0.13.5"
      arch:
        type: string
        default: "arm64"
    steps:
      - run:
          name: Install Terraform client
          command: |
            cd /tmp
            wget https://releases.hashicorp.com/terraform/<<
              parameters.version >>/terraform_<<
              parameters.version >>_linux_<<
              parameters.arch >>.zip
            unzip terraform_<< parameters.version >>_linux_<<
              parameters.arch >>.zip
            sudo mv terraform /usr/local/bin
jobs:
  run-tests:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - node/install-packages:
          override-ci-command: npm install
          cache-path: ~/project/node_modules
      - run:
          name: Run Unit Tests
          command: |
            ./node_modules/mocha/bin/mocha test/ --reporter mochawesome --reporter-options reportDir=test-results,reportFilename=test-results
      - store_test_results:
          path: test-results
      - store_artifacts:
          path: test-results
  build_docker_image:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - run:
          name: "Build Docker Image ARM V8"
          command: |
            export TAG='0.1.<< pipeline.number >>'
            export IMAGE_NAME=$CIRCLE_PROJECT_REPONAME
            docker build -t $DOCKER_LOGIN/$IMAGE_NAME -t $DOCKER_LOGIN/$IMAGE_NAME:$TAG .
            echo $DOCKER_PWD | docker login -u $DOCKER_LOGIN --password-stdin
            docker push -a $DOCKER_LOGIN/$IMAGE_NAME
  deploy_aws_ecs:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - run:
          name: Create .terraformrc file locally
          command: echo "credentials \"app.terraform.io\" {token = \"$TERRAFORM_TOKEN\"}" > $HOME/.terraformrc
      - install_terraform:
          version: 0.14.2
          arch: arm64
      - run:
          name: Deploy Application to AWS ECS Cluster
          command: |
            export TAG=0.1.<< pipeline.number >>
            export DOCKER_IMAGE_NAME="${DOCKER_LOGIN}/${CIRCLE_PROJECT_REPONAME}"
            cd terraform/aws/ecs
            terraform init
            terraform apply \
              -var docker_img_name=$DOCKER_IMAGE_NAME \
              -var docker_img_tag=$TAG \
              --auto-approve
  destroy_aws_ecs:
    machine:
      image: ubuntu-2204:current
    resource_class: arm.medium
    steps:
      - checkout
      - run:
          name: Create .terraformrc file locally
          command: echo "credentials \"app.terraform.io\" {token = \"$TERRAFORM_TOKEN\"}" > $HOME/.terraformrc
      - install_terraform:
          version: 0.14.2
          arch: arm64
      - run:
          name: Destroy the AWS ECS Cluster
          command: |
            cd terraform/aws/ecs
            terraform init
            terraform destroy --auto-approve
workflows:
  build:
    jobs:
      - run-tests
      - build_docker_image
      - deploy_aws_ecs
      - approve_destroy:
          type: approval
          requires:
            - deploy_aws_ecs
      - destroy_aws_ecs:
          requires:
            - approve_destroy

This code extends the original pipeline config example. As you may have already noticed, a few new jobs have been defined. The deploy_aws_ecs:, approve_destroy:, and destroy_aws_ecs: jobs are the new elements in this extended config. Before I dive into them I will describe the commands: and install_terraform: elements.

install_terraform: command

CircleCI is capable of encapsulating and reusing configuration code using pipeline parameters. The install_terraform: command is an example of defining reusable pipeline code. If your pipelines repeatedly execute specific commands, I recommend defining reusable command: elements to provide extensible and centrally managed pipeline configuration. Both the deploy_aws_ecs: and destroy_aws_ecs: jobs execute Terraform code, so the pipeline will need to download and install the Terraform cli more than once. The install_terraform: command provides valuable reusability.

commands:
  install_terraform:
    description: "specify terraform version & architecture to use [amd64 or arm64]"
    parameters:
      version:
        type: string
        default: "0.13.5"
      arch:
        type: string
        default: "arm64"
    steps:
      - run:
          name: Install Terraform client
          command: |
            cd /tmp
            wget https://releases.hashicorp.com/terraform/<<
              parameters.version >>/terraform_<<
              parameters.version >>_linux_<<
              parameters.arch >>.zip
            unzip terraform_<< parameters.version >>_linux_<<
              parameters.arch >>.zip
            sudo mv terraform /usr/local/bin

This code block defines the install_terraform: reusable command. The parameters: key maintains a list of parameters. The parameters version: and arch: define the Terraform CLI version and CPU architecture respectively. These parameters download and install the client in the executor. Because this block of code represents a command: element, a command steps: key must be defined. In the previous example, the run: element executes the corresponding command: key. This key downloads the specific Terraform client using the << parameter.version >> and << parameter.arch >> variables to specify the client version number and CPU architecture. Pipeline parameters are very useful for optimizing and centrally managing functionality within pipeline configuration. If you want to learn more, you can get all the details here.

deploy_aws_ecs job

The deploy_aws_ecs: job defined in the pipeline leverages infrastructure as code to create a new Amazon ECS cluster. It includes all of the required resources, such as virtual private networks (VPC), subnets, route tables, application load balancers, and EC2 auto scale groups. This job creates and provisions all the infrastructure needed to deploy and run applications. Because the target architecture is Arm, the AWS ECS cluster must be composed of AWS Gravtion2 ECS compute nodes. These nodes will execute the Arm based Docker application image build in previous pipeline jobs.

deploy_aws_ecs:
  machine:
    image: ubuntu-2204:current
  resource_class: arm.medium
  steps:
    - checkout
    - run:
        name: Create .terraformrc file locally
        command: echo "credentials \"app.terraform.io\" {token = \"$TERRAFORM_TOKEN\"}" > $HOME/.terraformrc
    - install_terraform:
        version: 0.14.2
        arch: arm64
    - run:
        name: Deploy Application to AWS ECS Cluster
        command: |
          export TAG=0.1.<< pipeline.number >>
          export DOCKER_IMAGE_NAME="${DOCKER_LOGIN}/${CIRCLE_PROJECT_REPONAME}"
          cd terraform/aws/ecs
          terraform init
          terraform apply \
            -var docker_img_name=$DOCKER_IMAGE_NAME \
            -var docker_img_tag=$TAG \
            --auto-approve

This code block demonstrates how to use the install_terraform: command I described previously. We have set the version: parameter to 0.14.2 and the arch: parameter to arm64. The final run: element initializes the terraform, code then executes a terraform apply command with corresponding parameters that pass through the values of the Docker image name and tag created in this pipeline run. Upon completion, this job will create and deploy the application to a fully functional AWS ECS Graviton2 based cluster.

destroy_aws_ecs job

We created the AWS ECS infrastructure in the deploy_aws_ecs. The destroy_aws_ecs jobs obviously performs the inverse and programmatically destroys all the infrastructure and resources created. This is the cleanest method of terminating unnecessary infrastructure.

destroy_aws_ecs:
  machine:
    image: ubuntu-2204:current
  resource_class: arm.medium
  steps:
    - checkout
    - run:
        name: Create .terraformrc file locally
        command: echo "credentials \"app.terraform.io\" {token = \"$TERRAFORM_TOKEN\"}" > $HOME/.terraformrc
    - install_terraform:
        version: 0.14.2
        arch: arm64
    - run:
        name: Destroy the AWS ECS Cluster
        command: |
          cd terraform/aws/ecs
          terraform init
          terraform destroy --auto-approve

In this code block, most of the job definition is the same as the previous one, except for the final run: element. In this element we are issuing a Terraform initialization and terraform destroy command which will, as expected, destroy all of the resources created in the previous step.

Workflows: approve_destroy job

The last item I will discuss is the approve_destroy: found in the workflows: element of the config example. This job is a manual approval type where workflow will be intentionally halted and remain in a hold until a manual interaction is completed. In this case, a button must be pressed in the CircleCI dashboard in order for the destroy-aws-ecs: to execute. Without this approval job, the pipeline would automatically trigger the destroy job and terminate all the resources created in previous jobs. Approval type jobs are useful for situations where manual intervention or approvals are required within pipeline executions.

With the pipeline configuration above properly defined, you should have a fully functional pipeline that can build, test, deploy, and destroy applications on Arm compute resources. The pipeline will also create and manage AWS ECS clusters with Graviton2 EC2 nodes using Terraform.

A successful pipeline run will look like this:

CircleCI pipeline

Conclusion

CircleCI has introduced Arm capable executors in the form of Arm compute nodes, giving developers access to Arm architectures for pipelines. In this tutorial I have demonstrated how to implement the CircleCI Arm compute nodes as pipeline executors. I have also shown how to deploy applications to AWS ECS clusters powered by AWS Graviton2 EC2 nodes using Terraform and infrastructure as code. All of the code examples in this tutorial can be found at in the arm-executors repo on GitHub and I highly encourage you to check it out. I would love to hear your feedback, thoughts, and opinions so please join the discussion by tweeting to me @punkdata.

Thanks for reading!
